Technical data
Max. element temperature | 230 °C (446 °F) |
|---|---|
Min. element temperature | -50 °C (-58 °F) |
Dielectric strength at 20°C AS per ASTM KV/mm | 21- 23 |
Thermal conductivity at 100 °C W/(m•K) | 0.24 |
Moisture absorption as per ASTM D-570-63. (24h immersion at 23°C) | 0.1 % |
Waterproof as per IEC 335-1 sect. 15-16 | yes |
Constant of dielectricity at 25°C, 50Hz | 2.9-3.6 |
Bending radius, min. | 3 mm |
Max. element width | 600 mm |
Power density | 1,3 W/cm² |
Resistance tolerance | As standard, ±10% of nominal.Tolerance down to ±2% available |
Rated voltage | Up to 1000 V AC/DC single or 3 phase |
Approvals/Standards | ETL (UL, V0, HB) |
