Technical data

Max. element temperature

70 °C (158°F)

Min. element temperature

-50°C (-58°F)

Dielectric strength at 20°C AS per ASTM KV/mm

175

Thermal conductivity at 100 °C W/(m•K)

0.16

Moisture absorption as per ASTM D-570-63. (24h immersion at 23°C)

0.8 %

Constant of dielectricity at 25°C, 50Hz

3.3 (PET)

Power density at -40°C

0.3 W/cm²

Resistance tolerance

±20%

Rated voltage

800 V

Other

Possible substrates: PET

Other heating technologies

Download

  • Printed Polymer PTC heaters.pdf pdf
    0.6MB, 2022-06-09 12:45:04
  • PTC curve.pdf pdf
    32kB, 2022-06-09 12:44:55
