Technical data

Max. element temperature

70°C (158°F)

Min. element temperature

-40°C (-40°F)

Dielectric strength at 20°C AS per ASTM KV/mm

15

Thermal conductivity at 100 °C W/(m•K)

0.17/70°C

Moisture absorption as per ASTM D-570-63. (24h immersion at 23°C)

0.2%

Waterproof as per IEC 335-1 sect. 15-16

yes

Constant of dielectricity at 25°C, 50Hz

5-9

Bending radius, min.

20 mm

Max. element width

600 mm

Power density

0.1 W/cm²

Resistance tolerance

As standard, ±10% of nominal.Tolerance down to ±2% available

Rated voltage

Up to 230 V AC/DC single or 3 phase
