Technical data
Max. element temperature | 105 °C (221°F) |
---|---|
Min. element temperature | -60°C (-76°F) |
Dielectric strength at 20°C AS per ASTM KV/mm | 175 |
Thermal conductivity at 100 °C W/(m•K) | 0.16 |
Moisture absorption as per ASTM D-570-63. (24h immersion at 23°C) | 0.8% |
Waterproof as per IEC 335-1 sect. 15-16 | yes |
Constant of dielectricity at 25°C, 50Hz | 3.3 |
Bending radius, min. | 1 mm |
Max. element width | 600 mm |
Power density | 0,6 W/cm² |
Resistance tolerance | As standard, ±10% of nominal.Tolerance down to ±2% available |
Rated voltage | Up to 1000 V AC/DC single or 3 phase |
