Technical data
Max. element temperature | 600°C (1112°F) |
|---|---|
Min. element temperature | -50°C (-58°F) |
Dielectric strength at 20°C AS per ASTM KV/mm | >25 |
Thermal conductivity at 100 °C W/(m•K) | 0.30 |
Moisture absorption as per ASTM D-570-63. (24h immersion at 23°C) | 1% |
Waterproof as per IEC 335-1 sect. 15-16 | NA |
Constant of dielectricity at 25°C, 50Hz | 4-5.5 |
Bending radius, min. | NA |
Max. element width | 600 mm |
Power density | 5 W/cm² (depending on application) |
Resistance tolerance | As standard, ±10% of nominal.Tolerance down to ±2% available |
Rated voltage | Up to 1000 V AC/DC single or 3 phase |
Other | Thickness min. 0,5 mm |
